Inverter (12VDC/0.5KW)

Availability: In Stock

Te Dhenat :

*Pure sine wave inverter

*4-step AVR

*Voltaxh i selektueshem ne hyrje (100V-290V or 145-290V) per perdorim shtepie ose rrjeti kompjutererik

*Amperazh i sekeltueshem 10A/20A Max(Opsional)

*Mundesi selektimi i baterise.(Perfshin baterite gel dhe lead-acid)

*Kompatibel me hyrjen e korentit ose te gjeneratorit

*Auto restart kur AC eshte duke u kthyer

*Mbrojtje nga mbitensioni ose qarqet e shkurtera

*Karikues baterie smart per optimizim dhe performance

*Cold start

*Overload and short circuit protections
*Smart battery charger design for optimized battery performance
*Cold start
*XLS series also have built-in PWM controller inside.

Add to wishlist

Compare

Description
Reviews (0)

Description

Specifications

XL Series(Sine wave inverter)
Model #	X-600	X-1200
Capacity	600VA/500W	1200VA/1KW
Power factor	0.8
INPUT
Input voltage range	Inverter mode: 100~290Vac±5Vac
	UPS mode: 145~275Vac±5Vac
Input Frenquency	45~65Hz
OUTPUT
Output voltage range	Inverter mode: 150~255Vac±5Vac
	UPS mode: 203~238Vac±5Vac
Output frequency	50Hz ±0.1Hz (DC mode)
Wave form	Pure sine wave (DC Mode)
Transfer time	<10ms.
BATTERY
Charging current(AC)	10A/20A/Max.
Type of battery(optional)	GEL/ Sealed lead acid/ Open lead acid
PHYSICAL
Unit dimension (mm)	290255120
Net weight for XL Series(KG)	7.6	12.2
Environment	Temperature 0℃~40℃， Humidity 20%~90%
Noise Level	≤40dB(1m)
